Electrical connectors called brass insulated spade terminals are frequently used in circuit assembly and wiring. They are made to quickly and securely connect and disconnect wires, particularly in industrial, domestic, and automobile settings.
Brass insulated spade terminals are built of brass because of its superior corrosion resistance, durability, and conductivity. They slide into connection points like barrier strips or screw terminals with ease thanks to their spade shape. Insulation helps avoid short circuits and offers electrical safety.
Key Features:
-
Material: Brass (tin-plated or bare)
-
Insulation: PVC, Nylon, or Heat Shrink
-
Types:
-
Male/Female Spade
-
Straight or Angled (Flag)
-
Vinyl/Nylon Insulated
-
-
Wire Size Compatibility: Typically 22–10 AWG
-
Temperature Rating: Varies by insulation type (up to 105°C for PVC, higher for nylon/heat shrink)
Applications:
-
Automotive wiring
-
Electrical panels
-
Home appliances
-
Industrial machines
-
Marine wiring
Advantages:
- Easy to install and remove
- Reusable
- Provides strong mechanical and electrical connection
- Color-coded insulation (for easy wire gauge identification)
Popular Variants:
| Type | Wire Gauge | Insulation Color | Stud Size |
|---|---|---|---|
| Vinyl Insulated Spade | 16-14 AWG | Blue | #6, #8, #10 |
| Nylon Insulated Spade | 22-16 AWG | Red | #6, #10 |
| Heat Shrink Spade | 12-10 AWG | Yellow | #8, #10 |
More information
- Sample Time:Available in 5-10 days for different items.
- Drawing Format:CAD / PDF / DWG / IGS / STEP.
- Packaging:Standard package, Carton box or Pallet, As per customized specifications
- Shipping:DHL, FEDEX, UPS and By Sea or as per client’s requirements.
