Copper Ground Clamp
🔎 What is a Copper Ground Clamp?
A Copper Ground Clamp is a mechanical device used to securely connect a copper grounding conductor to a grounding electrode such as a ground rod, water pipe, or structural steel. This connection ensures proper dissipation of electrical fault currents or lightning strikes into the earth.
copper ground clamp, grounding clamp, electrical ground clamp, UL ground clamp, pipe ground clamp, ground rod clamp, copper bonding clamp, earthing clamp, bronze ground clamp, grounding connector
🧱 Construction and Material
-
Material: High-conductivity copper, bronze, or copper alloys
-
Design: Usually includes a saddle or U-bolt design with screws or bolts for secure tightening
-
Coating: Often corrosion-resistant or tinned for outdoor/buried applications
-
Certifications: Typically UL 467 Listed and compliant with NEC (National Electrical Code)
⚙️ Function and Working
-
Ensures low-resistance path from the electrical system to earth
-
Prevents damage to equipment or structures from fault currents or lightning
-
Creates a permanent, mechanical bond between conductor and grounding electrode
🧩 Types of Copper Ground Clamps
| Type | Description |
|---|---|
| Pipe Ground Clamp | Attaches grounding wire to metal water or gas pipes |
| Rod Ground Clamp | Secures grounding wire to copper or galvanized ground rods |
| Heavy-Duty Clamp | Designed for industrial or high-amperage grounding systems |
| Universal Clamp | Adjustable for multiple conductor sizes and electrode diameters |
| Split Bolt Clamp | Used to splice two conductors or tap off a ground wire |
🏗️ Applications
- Residential and commercial electrical grounding
- Lightning protection systems
- Grounding of transformers, panels, and distribution boards
- Earthing water pipes, fences, and structural steel
✅ Key Features
- High electrical conductivity
- Strong mechanical hold
- Resistant to corrosion and weathering
- Compatible with a range of wire gauges and pipe/rod diameters
- Easy to install with basic tools
📐 Common Sizes and Wire Ranges
| Clamp Size | Pipe/Rod Range | Conductor Range |
|---|---|---|
| Small | 1/2" to 1" | #14 AWG – #6 AWG |
| Medium | 1/2" to 2" | #10 AWG – 2/0 AWG |
| Heavy-Duty | 1" to 4" | #6 AWG – 4/0 AWG |
📎 Installation Tips
- Clean the surface of rod/pipe before clamping
- Ensure clamp is tightly secured
- Use dielectric grease for long-term corrosion resistance (if needed)
- Avoid overtightening to prevent damage to conductor or clamp
