Copper Spike
⚡ Copper Spike – Product Detail
Copper Spikes** are solid copper or copper-bonded earthing rods designed for safe and efficient dissipation of fault currents into the ground. These spikes are essential components in grounding systems for electrical safety, helping to stabilize voltage levels and protect equipment and personnel from lightning strikes and electrical faults.
Often driven directly into the ground, copper spikes are used where permanent, low-resistance grounding is required, especially in industrial, commercial, and utility-scale installations.
- Copper Spike,
- Copper Earthing Spike,
- Copper Grounding Spike,
- Solid Copper Earth Rod,
- Copper-Bonded Ground Rod,
- Electrical Grounding Spike,
- Earthing Rod Copper,
- Lightning Protection Spike,
- Copper Ground Spike India,
- Corrosion-Resistant Earth Spike
🛠️ Construction & Design:
-
Material Options:
-
Solid Copper (ETP grade – Electrolytic Tough Pitch)
-
Copper-Bonded Steel (typically with 99.9% pure copper coating)
-
-
Type:
-
Tapered/Pointed end for easy driving into the ground
-
Flat or threaded top for clamp or connector attachment
-
-
Lengths Available:
-
1 meter, 1.5 meters, 2 meters, and custom lengths
-
-
Diameter Range:
-
12 mm, 14 mm, 16 mm, 20 mm (or as specified)
-
-
Finish:
-
Natural copper finish, corrosion-resistant
-
📏 Technical Specifications:
| Parameter | Specification |
|---|---|
| Material | Solid Copper or Copper-Bonded Steel |
| Copper Thickness (if bonded) | 250 microns (standard) |
| Diameter Range | 12 mm – 20 mm |
| Length Range | 1 m – 3 m (standard/custom) |
| Surface Finish | Natural Copper |
| Tensile Strength | > 600 N/mm² (copper-bonded) |
| Standards | UL 467, IEC 62561-2, IEEE, IS:3043 |
⚙️ Applications:
- Electrical grounding for substations, buildings, towers
- Lightning protection systems
- Renewable energy grounding (solar/wind farms)
- Telecom tower earthing systems
- Grounding of generators, transformers, and panels
🌟 Key Features & Benefits:
-
✔️ Low electrical resistance to earth
-
✔️ Highly corrosion-resistant in all soil conditions
-
✔️ Easy installation with hammer or driving head
-
✔️ Long-lasting performance (up to 30+ years in proper soil)
-
✔️ Compatible with ground clamps, rods, or chemical electrodes
Other Information
✔️ Sample Time: Available in 5-10 days for different items.
✔️ Drawing Format: CAD / PDF / DWG / IGS / STEP.
✔️ Packaging: Standard package, Carton box or Pallet, As per customized specifications
✔️ Shipping: DHL, FEDEX, UPS and By Sea or as per client’s requirements.
